BM-Lactate Bx/25

BM-Lactate Bx/25

The Lactate test strip is made up of four layers as follow

• The top layer - a yellow mesh to which blood is applied
• The second layer - composed of a glass fibre layer which separates the erythrocytes (red blood cells)
• The third layer - this is where the chemical reactions take place - the lactate in the blood plasma reacts with chemicals in this layer
• The base layer is a support layer that is the length of the strip

Specifications:

• UOM: Bx/25
• Measuring Range: 0.8-22 mmol/L
• Measuring Time: 60secs
• Sample Materials: Fresh capillary blood, Use of heparin-coated pipettes possible
• Sample Volumes:15–50 µ L
• Operating conditions: 5° – 35°C or
  15° – 35°C depending on concentration of analyte

Images is sample of product
